NIJ Level IV Body Armor Plate is the highest grade of body armor, surpassing the capabilities of Level III and better than Kevlar armor.
The NIJ (National Institute of Justice) standard 0101.06 certifies this armor. This standard means the armor can withstand armor-piercing .30 caliber rounds traveling between 2,850 and 2,910 fps.
The NIJ requirement is for the armor to withstand a single shot in a conditioned state. However, our Level IV plates have been tested and proven against multiple rounds from various full-automatic weapons.
The Armor Plates are ergonomically designed with a real ESAPI Shooter's cut and body curve for accurate shooting and arm movement.
We offer two sizes of plates: 10x12x0.9 in and 11x14x0.9 in, to fit any armor carrier in our lineup.
Our Level IV armor plate is a standalone plate, meaning it can stop high velocity rounds by itself without the need for additional armor.
The plates are constructed from durable ceramic materials with PEAD™ (polyethylene) backing, making it spike proof and stab proof.
They are available in two exterior coating options: Standard Ceramic and Boron Carbide.
These plates also offer versatility, as they can be used in a carrier vest or fit into civilian items like purses or backpacks for added protection.
NIJ Level IV Body Armor Plate Review
NIJ Level IV Body Armor Plate Features
NIJ IV Tested: The NIJ Level IV Body Armor Plate is designed to block and stop various armor-piercing rounds, including sniper, pistol, and assault rifle rounds. It offers top-end ballistic protection and can effectively stop AP & API rounds from AK-47 and other rifles.
Ergonomic Design: Shaped to match your body for a comfortable fit. It features a real ESAPI Shooter's cut and body curve which allows for accurate shooting and arm movement.
Advanced Materials: It uses military-grade PEAD™ and ceramic mil-spec armoring, providing higher protection than Level III and better than Kevlar armoring.
Multiple Buying Options: Both wholesale and retail options are available.
Compliance with Standards: The model complies with NIJ Standard-0101.06 for Ballistic Resistance of Body Armor. It also meets the standards of VPAM PM 12/13, TR SK4/PM9, HOSDB SG3 and RF2, GOST Class 6/6A, GOST BR5/BR6, XSAPI - REV. C., and ESAPI - REV. J.
Versatile Use: The NIJ Level IV Body Armor Plate can be used in a carrier vest or it can be fitted into purses or backpacks for a reliable line of defense in civilian settings.
Different Sizes: Available in two sizes - 10x12x0.9 in or 11x14x0.9 in, ensuring a proper fit for different body types and equipment.
What's in the box of the NIJ Level IV Body Armor Plate?
NIJ level IV ballistic plate in your chosen size
NIJ Level IV Body Armor Plate Specifications
Cut: XSAPI/ESAPI (Military standard)
Weight Options:
Standard (10"x12"): 6.6 pounds / 3 kg
Standard (11"x14"): 8.8 pounds / 4 kg
B4C (10"x12"): 4 pounds / 1.8 kg
B4C (11"x14"): 6 pounds / 2.8 kg
Material: Constructed with ceramic materials and PEAD™ (polyethylene) backing
Available Sizes:
10x12x0.9 in (25x30x2.3 cm)
11x14x0.9 in (27x35x2.3 cm)
Compliance: The model complies with multiple ballistic resistance standards including NIJ Standard-0101.06 for Ballistic Resistance of Body Armor, NIJ level IV (4) under standard 0101.06, VPAM PM 12/13, TR SK4/PM9, HOSDB SG3 and RF2, GOST Class 6/6A, GOST BR5/BR6, XSAPI - REV. C. and ESAPI - REV. J.
Protection Level: As a Level IV armor, these plates can stop armor-piercing (AP) .30 caliber rounds traveling between 2,850 and 2,910 fps, along with multiple rounds from various full-automatic weapons.
Options: The NIJ Level IV plates fit any carrier in our lineup. The X-Line Coating 10x12 Armor Plate fits our 10x12 Armor Plate Carrier, while the X-Line Coating 11x14 Armor Plate corresponds with the 11x14 Armor Plate Carrier.
NIJ Level IV Body Armor Plate FAQs
How much does the NIJ Level IV Body Armor Plate weigh?
Depending on the size and cut, the weights range from 4 pounds (1.8 kg) to 8.8 pounds (4 kg).
What type of rounds can this armor plate withstand?
The NIJ Level IV Body Armor Plate can withstand various types of rounds, including armor-piercing .30 caliber rounds, 7.62mm AP/API, 5.56mm AP/API, and many more.
What are the available sizes for the NIJ Level IV Body Armor Plate?
We offer two sizes - 10x12x0.9 in (25x30x2.3 cm) and 11x14x0.9 in (27x35x2.3 cm).
Can the NIJ Level IV Body Armor Plate be used on its own?
Yes, it's a Level 4 Standalone plate, meaning it can stop various calibers by itself, without needing additional armor behind it.
Is the NIJ Level IV Body Armor Plate comfortable to wear?
Yes, our plates are ergonomically designed with a shooter's cut to allow for comfortable weapon handling and firing. The curvature is designed to match your body shape for a comfortable fit.
What is the material composition of the NIJ Level IV Armor Plate?
Our plates are composed of sturdy ceramic material with a PEAD™ (polyethylene) backing for increased durability and protection.
Is this a Level IV (4) Standalone Plate or ICW Plate?
Level 4 Standalone. This means that it can stop up to 30-06 MW AP, .308, 6.5 Creedmoor, 5.56x45 Armor Piercing BT, 9mm, .44 Magnum, 7.62x39 FMJ, etc. by itself and without extra armor needing to be placed behind it.
What is the difference between Standard Ceramic versus Boron Carbide?
You're choosing the exterior coating for X-line or Fabric. Fabric
What Is NIJ Level 4?
At Atomic Defense, we test our panels to comply with and exceed the National Institute of Justice's (NIJ) regulations. The NIJ's standards categorize equipment by the types of rounds it can hold to a depth of 44 mm or less upon impact. Each NIJ level represents a stronger body armor, where levels III and higher fall into the category of hard body armor. Level IV ceramic armor plates are the highest grade for body armor under NIJ standard 0101.06, withstanding rounds from each previous level and above.
As Level IV armor, these plates meet the NIJ's requirement of stopping armor-piercing (AP) .30 caliber rounds traveling between 2,850 and 2,910 fps. The NIJ requires that hard body armor meets this qualification against a single shot in a conditioned state. We go beyond the NIJ's Level IV requirements by firing numerous shots into the armor, proving it can withstand multiple rounds from various full-automatic weapons.
Why Go With Insert Panels?
Insert panels like Atomic Defense's NIJ Level IV Bulletproof Inserts offer the highest ballistic protection and the versatility to use them as you see fit. You can use these panels in a carrier vest, loading both sides to prioritize coverage or removing one for greater mobility.
Insert plates also fit well into purses or backpacks for a reliable line of defense in civilian settings. Dependable and lightweight, these PE and ceramic insert panels are the perfect body armor for any wearer.
Which Size Is Insert Is Right for Me?
Finding equipment that fits your body and equipment is essential for combat preparation, whether you're a civilian, police officer or U.S. military member. Our NIJ Level IV plates fit any carrier in our lineup.
The X-Line Coating 10x12 Armor Plate fits our 10x12 Armor Plate Carrier, while the X-Line Coating 11x14 Armor Plate corresponds with the 11x14 Armor Plate Carrier.
Browse our carrier selection online or contact an Atomic Defense representative to ensure your plates and carrier match up.
